12 layers BGA PCB Board for Medical Electronics

UL&IPC Standard & ISO
  • Layer:

    12 L
  • Material:

    Fr-4
  • PCB Thickness:

    1.6mm
  • Cu Thickness:

    2.0 OZ
  • Min line W/S:

    0.075/0.075mm
  • Surface finish:

    Immersion gold
  • Certificate:

    UL/ISO/IATF16949
  • Application:

    Medical Electronics
  • Product Detail

Item

Speci.

Layers

1~32

Board thickness

0.1mm-7.0mm

Material

FR-4CEM-1/CEM-3PIHigh TgRogers

Max panel size

32"×48"(800mm×1200mm)

Min hole size

0.075mm

Min line width

3mil(0.075mm)

Surface finish

OSPHASLImm Gold/Nickel/Ag Electric gold

Copper thickness

0.5-7.0OZ

Soldermask

Green/Yellow/Black/White/Red/Blue

Silkscreen

Red/Yellow/Black/White

Min PAD

5mil(0.13mm)

Inter package

Vacuum

Outer package

Carton

Outline tolerance

±0.075mm

Hole tolerance

PTH±0.05 NPTH±0.025

Certificate

ULISO 9001ISO14001IATF16949

Special request

Blind hole+Gold finger  + BGA

Material Suppilers

 Shengyi, KB, Nanya, ITEQ,etc.



Quality And Policy

Continually improve our quality, efficiency, service to satisfy thecustomer's requirement.
Quality Specifications:


Quality System


1. ISO-9001:2018 Quality System Standard
2. Quality Standard: IPC-610-D class 2,
3. Soldering Standard: J-STD-001 class 1,2,3
4. ESD Standard: ESD-MIL-STD-1686
5. Workshop management:5S
6. FAI-first article inspection
7. In process visual inspection
8. AOI inspection
9. Machine calibration and preventative maintenance


RoHS Management

Product compliant: RoHS
RoHS prohibited substances list :
    NO.     Name                       The upper limit(ppm=mg/kg)
      1        Pb                                0.1%(1000ppm)
      2        Hg                                0.1%(1000ppm)
      3        Cd                                0.001%(100ppm)
      4        Cr VI+                          0.1%(1000ppm)
      5        PBB                             0.1%(1000ppm)
      6        PBDE                          0.1%(1000ppm)



Deliver Time For PCB & PCBA


1.   PCB production time:  sample:  3-4 days /   production: within 7 days

2.   Fast pcb delivery: 24 hours for 2L ; 48 hours for 4L ; 72 hours for 6L.

3.  Component purchase: 2 days if all components is available in our domestic market.

4.  PCB Assembly:  samples: within 8 days / mass production: within 12 days


LAYER

PROTOTYPE

MASS PRODUCTION   (above 20 m2)

Quick Turn

Standard Time

MC PCB

48 hours

4-5 days

10-12 days

PFC 1 L

48 hours

5-6 days

12-13 days

1L

24 hours

3-4 days

8-10 days

2L

24 hours

3-4 days

8-10 days

4L

48 hours

5-6 days

8-10 days

6L

72 hours

6-7 days

10-12 days

8L

72 hours

7-8 days

12-14 days

10L

96 hours

9-10days

16-18 days
