Multilayer Gold Finger Board for Computer Electronics

UL&IPC Standard & ISO
  • Layer:

    4 L
  • Material:

    Fr-4
  • PCB Thickness:

    1.3mm
  • Cu Thickness:

    1.0 OZ
  • Min line W/S:

    0.1/0.1mm
  • Surface finish:

    Immersion gold
  • Certificate:

    UL/ISO/IATF16949
  • Application:

    Computer Electronics
  • Product Detail

Item

Speci.

Layers

1~32

Board thickness

0.1mm-7.0mm

Material

FR-4CEM-1/CEM-3PIHigh TgRogers

Max panel size

32"×48"(800mm×1200mm)

Min hole size

0.075mm

Min line width

3mil(0.075mm)

Surface finish

OSPHASLImm Gold/Nickel/Ag Electric gold

Copper thickness

0.5-7.0OZ

Soldermask

Green/Yellow/Black/White/Red/Blue

Silkscreen

Red/Yellow/Black/White

Min PAD

5mil(0.13mm)

Inter package

Vacuum

Outer package

Carton

Outline tolerance

±0.075mm

Hole tolerance

PTH±0.05 NPTH±0.025

Certificate

ULISO 9001ISO14001IATF16949

Special request

Blind hole+Gold finger  + BGA

Material Suppilers

 Shengyi, KB, Nanya, ITEQ,etc.



Gold Finger PCB


Gold Finger PCB is a type of printed circuit board that has gold-plated edge connectors. The gold plating provides a highly conductive and corrosion-resistant surface, which makes it an ideal choice for high-performance applications.


PCB Manufacturing Services


As one of the leading Printed Circuit Board manufacturers based in China, Ucreate has been offering international companies of all sizes with high-quality PCB prototype to production services at a fair price for eight years. To make professional and advanced circuit boards, we're committed to adhering to the strictest standards during the PCB manufacturing process. We're fully compliant with the ISO 9001:2008 quality management system.

- Save money&time! Achieve peace of mind!
- A professional and trustworthy PCB Prototype manufacturer.
Fastest PCB Prototype.
- One-stop solution for various PCB& SMT Stencil.
- Low cost for simple PCB.
- Affordable price for high-tech PCB.
- Minimum orders 1pcs.
- 24-hour online customer service.
- Professional PCB engineer for one-to-one service.
- Shipment on time.
- Guarantee good service and quality from PCB quotation to delivery.


PCB Assembly Services


To deliver real value and convenience to our PCB fabrication clients, we expand our business to components sourcing and turnkey PCB assembly services ranging from the prototype, low-to-middle volume to high volume up to 1 million pcs. We can mount components on circuit boards using surface mount technology (SMT),through-hole technology (THT), and manual insertion:

- High-quality assembly services with short lead times
- No minimum order
- No additional charge for stencils
- Free DFM Check
- 100% AOI test and X-Ray test for BGAs package
- Function tests & IC programming based on custom requirements

All boards are produced according to IPC-6012 standards and inspected according to IPC-A-600 in the latest version. Our products are widely applied in communications, industrial control, power electronics, medical equipment, security electronics, consumer electronics, LED, etc. More than 90 percent of them were exported to Europe, North America, South America.


Deliver Time For PCB & PCBA


1.   PCB production time:  sample:  3-4 days /   production: within 7 days

2.   Fast pcb delivery: 24 hours for 2L ; 48 hours for 4L ; 72 hours for 6L.

3.  Component purchase: 2 days if all components is available in our domestic market.

4.  PCB Assembly:  samples: within 8 days / mass production: within 12 days


LAYER

PROTOTYPE

MASS PRODUCTION   (above 20 m2)

Quick Turn

Standard Time

MC PCB

48 hours

4-5 days

10-12 days

PFC 1 L

48 hours

5-6 days

12-13 days

1L

24 hours

3-4 days

8-10 days

2L

24 hours

3-4 days

8-10 days

4L

48 hours

5-6 days

8-10 days

6L

72 hours

6-7 days

10-12 days

8L

72 hours

7-8 days

12-14 days

10L

96 hours

9-10days

16-18 days



One-stop Service Include


PCB Prototype

Quick Turn PCB

Single-Sided PCB

Double-Sided PCB

Multilayer PCB

Rigid PCB

Flexible PCB

Rigid-Flex PCB

LED PCB

Aluminum PCB

Metal Core PCB

Thick Copper PCB

HDI PCB

BGA PCB

High TG PCB

PCB Stencil

Impedance Control PCB

PCB Assembly

High-Frequency PCB

Bluetooth Circuit Board

Automotive PCB

USB Circuit Board

Halogen-Free PCB

Antenna PCB
