Chinese Copper base PCB board for Industry Control

UL&IPC Standard & ISO
  • Layer:

    1 L
  • Material:

    Copper
  • PCB Thickness:

    2.0mm
  • Cu Thickness:

    1.5 OZ
  • Min line W/S:

    0.3/0.2mm
  • Surface finish:

    Immersion gold
  • Certificate:

    UL/ISO/IATF16949
  • Application:

    Industrial Control
  • Product Detail

Item

Speci.

Layers

1~32

Board thickness

0.1mm-7.0mm

Material

FR-4CEM-1/CEM-3PIHigh TgRogers

Max panel size

32"×48"(800mm×1200mm)

Min hole size

0.075mm

Min line width

3mil(0.075mm)

Surface finish

OSPHASLImm Gold/Nickel/Ag Electric gold

Copper thickness

0.5-7.0OZ

Soldermask

Green/Yellow/Black/White/Red/Blue

Silkscreen

Red/Yellow/Black/White

Min PAD

5mil(0.13mm)

Inter package

Vacuum

Outer package

Carton

Outline tolerance

±0.075mm

Hole tolerance

PTH±0.05 NPTH±0.025

Certificate

ULISO 9001ISO14001IATF16949

Special request

Blind hole+Gold finger  + BGA

Material Suppilers

 Shengyi, KB, Nanya, ITEQ,etc.



What's a Aluminum PCB


The aluminum substrate is a metal-based copper-clad plate with good heat dissipation function. Generally, the single-sided board is composed of a three-layer structure, which is a circuit layer (copper foil), an insulating layer, and a metal base layer. Aluminum substrates are rarely made into double-sided circuit boards, and double-sided circuit boards will affect its heat dissipation and other functions. Aluminum substrates are commonly used in LED lighting, such as: industrial led light boards, automotive car light boards, medical surgery LED light boards, display screen led light boards and so on. The aluminum substrate has both front and back sides. Usually the back side is unpackaged and presents the true color of aluminum. On the other side, the white side is soldered to the LED pins. Generally, the thermally conductive paste is applied to the thermally conductive part after contact. There are ceramic substrates and so on.




Deliver Time For PCB & PCBA


1.   PCB production time:  sample:  3-4 days /   production: within 7 days

2.   Fast pcb delivery: 24 hours for 2L ; 48 hours for 4L ; 72 hours for 6L.

3.  Component purchase: 2 days if all components is available in our domestic market.

4.  PCB Assembly:  samples: within 8 days / mass production: within 12 days


LAYER

PROTOTYPE

MASS PRODUCTION   (above 20 m2)

Quick Turn

Standard Time

MC PCB

48 hours

4-5 days

10-12 days

PFC 1 L

48 hours

5-6 days

12-13 days

1L

24 hours

3-4 days

8-10 days

2L

24 hours

3-4 days

8-10 days

4L

48 hours

5-6 days

8-10 days

6L

72 hours

6-7 days

10-12 days

8L

72 hours

7-8 days

12-14 days

10L

96 hours

9-10days

16-18 days



One-stop Service Include


PCB Prototype

Quick Turn PCB

Single-Sided PCB

Double-Sided PCB

Multilayer PCB

Rigid PCB

Flexible PCB

Rigid-Flex PCB

LED PCB

Aluminum PCB

Metal Core PCB

Thick Copper PCB

HDI PCB

BGA PCB

High TG PCB

PCB Stencil

Impedance Control PCB

PCB Assembly

High-Frequency PCB

Bluetooth Circuit Board

Automotive PCB

USB Circuit Board

Halogen-Free PCB

Antenna PCB
